Prime Inventions Aqua Fidelo 20" Mains Water Pre-Filter incl. Sediment Filter
Description
Prime Inventions Aqua Fidelo 20" incl. Sediment Filter 25 & 1 my
- For efficient filtration of turbidity and sediment.
- The perfect complement to your whole-house water filter.
- Ideal for preventing premature clogging of your activated carbon whole-house water filter.
- Significantly extends the service life of downstream activated carbon cartridges.
- Also usable individually for sediment and turbidity filtration (without a combined whole-house water filter).
- High-quality and robust filter housing made of polypropylene.
- Innovative textile filter from Pentek/Pentair: Two different mesh sizes (25 & 1 µm) for particularly effective filtration.
- Device wrench, ball valve (inlet and outlet), reducing nipple, and steel wall bracket included in the set.
- Filter housing manufactured in Europe.
Compatible filter cartridges
- The Prime Inventions Aqua Fidelo 20" set comes with a Pentair combination pre-filter cartridge with 25 & 1 µm.
- Here you can find Pentek DGB 2 Stage Sediment Filter 20" (25 & 1 µm) replacement cartridges.
- For hygienic reasons, we recommend replacement of the cartridges every 12 months. High sediment levels may necessitate more frequent changes.
Installation
- The Aqua Fidelo 20-inch housing has a 6/4" female thread on both the inlet and outlet sides.
- 1" reducers, double nipples, and a 1" ball valve are included for installation.
- A very sturdy wall bracket made of solid steel is included for mounting.
- Must only be used with cold water and must be protected from frost.
- The manufacturer recommends using the housing only up to a water pressure of 4.5 bar. A pressure reducer is recommended for higher water pressures.
Scope of delivery
This Prime Inventions Aqua Fidelo 20" incl. Sediment Filter 25/1 µm kit contains the following parts:- one Aqua Fidelo 20" filter housing
- one two stage Pentair pre-filter cartridge with 25 and 1 µm
- one wall bracket made of powder-coated steel
- one device key
- two reducers 6/4" to 1" made of stainless steel (AISI 316)
- two 1" double nipples made of stainless steel (AISI 316)
- two 1" ball valves made of brass
Dimensions and further information about the Prime Inventions Aqua Fidelo 20"
| Type of connection: | Whole house water filter |
|---|---|
| H x W x D: | 680 x 360 x 220 mm (Width with ball valves installed) |
| Material: | PP (housing), blown polyester (catridge) |
| Length of the filter cartridge: | 508 mm | 20" |
| Filter mesh: | 25 & 1 µm |
| Flow rate (at 4 bar): | 60 l/min |
| Max. useful life of the filter cartridge: | 12 months |
| Connection: | 1" internal thread |
